1.27mm SMD Double Row Female Socket (HS127SB-XXXX)

1.27mm Pitch Socket/Double Rows/SMD/H: S1: 3.6mm, S2: 4.5mm

product details

Feature

The 1.27mm SMD double row socket is characterized by its precision engineering and premium materials, ensuring superior performance and durability. The socket has a 1.27 mm pitch and is designed to provide a safe and stable connection to surface mount devices, making it suitable for use in compact and space-constrained applications.

Specifications

Current Rating	1 A
Voltage Rating	AC/DC 30 V
Contact Resistance	20mΩMax.
Operating Temperature	-40℃~+105℃
Insulation Resistance	1000MΩ
Withstanding Voltage	500V AC/60S
Max Processing Temperature	260℃ for 10 Seconds
Contact Material	Copper Alloy, Plating Au/ Sn or others
Housing Material	Thermoplastic or High Temperature Thermoplastic, UL 94V-0

Dimension Drawings

Advantages

One of the main advantages of the 1.27mm SMD dual-row socket is its dual-row design, which improves connectivity and signal density. This feature makes it an excellent choice for applications that require a high level of functionality in a limited space, such as mobile devices, consumer electronics, and industrial control systems.

In addition to its compact design, the 1.27mm SMD double row socket offers excellent electrical performance, low contact resistance and high current carrying capacity. This ensures reliable signal transmission and power delivery, making it suitable for a variety of high-speed and high-frequency applications.

The socket is also designed for easy and efficient assembly, and its surface mount configuration simplifies the manufacturing process and reduces production costs. Its durable construction and rugged materials make it suitable for use in harsh operating environments, providing long-term reliability and performance.

The 1.27mm SMD dual-row socket is compatible with multiple industry standard specifications and can be easily integrated into existing designs and systems. Its versatility and compatibility make it ideal for OEMs and electronics manufacturers looking for reliable and cost-effective connectivity solutions.

Applications

1.27mm SMD double row sockets have a wide range of applications, including but not limited to:

Mobile devices: The compact size and high-density connectivity make this outlet ideal for smartphones, tablets and wearable devices where space is at a premium.
Consumer Electronics: From digital cameras to game consoles, the socket’s high-performance characteristics make it suitable for a variety of consumer electronics applications.
Industrial Control Systems: The socket’s rugged construction and reliable performance make it ideal for industrial automation, robotics and other control systems.
Networking and Telecommunications: The high-speed and high-frequency capabilities of this outlet make it an excellent choice for networking equipment, routers, and telecommunications equipment.

All in all, the 1.27mm SMD dual-row socket offers the perfect combination of compact design, high performance and versatility, making it ideal for a variety of electronic applications. Its precision engineering, reliable connections, and compatibility with industry standards make it a valuable component for OEMs and electronics manufacturers looking for reliable and cost-effective connectivity solutions.
