0.8mm Pitch Single Slot BTB Female Connector (BP080SA-1580)

This cutting-edge connector is designed to meet the demands of high-speed data transmission and offers a range of features that make it ideal for a variety of applications.

The connector features a 0.8mm pitch and is optimized for high-density applications where space is at a premium. The welding type is SMT, ensuring a reliable, strong connection that can withstand harsh environments. The connector is available in multiple pin options, including 30, 40, 50, 60, 80, 100, 120 and 140, providing flexibility to meet a variety of design requirements.

The connection type is vertical, making it suitable for applications where vertical orientation is preferred. With a transmission speed of 12 Gbps, the connector can handle high-speed data transfers with ease, making it ideal for applications where speed and reliability are critical.

Stacking heights of 5 - 20 mm provide greater flexibility, allowing customization to meet specific design requirements. This makes the 0.8mm pitch single slot BTB female connector a versatile solution that can be customized to meet the needs of a variety of applications.

Whether in consumer electronics, telecommunications, industrial equipment or other fields, this connector is expected to deliver superior performance and reliability. Its rugged construction and high-speed capabilities make it ideal for applications where performance and durability cannot be ignored.

In summary, the 0.8mm pitch single-slot BTB female connector represents a leap forward in connector technology. With its high-speed capabilities, flexible pin options and rugged construction, it meets the needs of the most challenging applications. Whether you are designing the next generation of consumer electronics or pushing the boundaries of industrial technology, this connector can meet your needs.
